Scott Foil Premium Disc - Shimano Dura-Ace R9170 Road Bike
- Description
The 2019 Scott Foil Premium Disc - Shimano Dura-Ace R9170 wins stages at all the grand tours, classic victories at Milan San Remo, Liege Bastogne Liege and Paris-Roubaix - we can safely say that the FOIL Premium is the most versatile aero bike on the market. Its HMX Carbon fiber frame was designed to help you gain those extra precious seconds, and comes in as one of the lightest in the aero market. With the SCOTT Foil Premium's Syncros integrated handlebar system, Dura-Ace Di2 and Syncros Carbon components, this bike will help you win every ride.
-
FRAME: FOIL DISC HMX / IMP, F01 AERO Carbon tech. Road Race geometry. Replaceable Derailleur Hanger
-
FORK: FOIL DISC HMX
1 1/4"-1 1/2" Carbon steerer
Integrated Carbon Dropout -
HEADSET: Syncros Integrated
-
REAR DERAILLEUR: Shimano Ultegra Di2 RD-R8050
22 Speed Electronic Shift System -
FRONT DERAILLEUR: Shimano Dura-Ace Di2 FD-R9150 Electronic Shift System
-
SHIFTERS: Shimano Dura-Ace Di2 ST-R9170 Dual control 22 Speed Electronic Shift System
-
BRAKES: Shimano BR-R9170 Hyd Disc 160/F and 160/R SM-RT900 CL rotor
-
CRANKSET: Shimano Dura-Ace FC-R9100 Hollowtech II 52x36 T (2nd gen)
-
BB-SET: Shimano SM-BB92-41B
-
HANDLEBAR: Syncros RR 1.0 Aero
-
SEATPOST: Syncros Duncan 1.0
-
SEAT: Syncros Belcarra V-Concept 1.0
-
WHEELSET: Zipp 303s
- Rotors: Shimano RT-MT800 Rotors
- Chain: Shimano Ultegra CN-HG701-11 11 Speed Chain
- Cassette: Shimano Ultegra CS-HG800-11 11 Speed Cassette
| EN |
|
|
|
|
|
|
|
|||
|---|---|---|---|---|---|---|---|---|---|---|
| A | HEAD TUBE ANGLE | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° | ||
| B | HEAD TUBE LENGTH | 110.0 MM | 115.0 MM | 130.0 MM | 150.0 MM | 170.0 MM | 190.0 MM | 210.0 MM | ||
| C | TOP TUBE HORIZONTAL | 510.0 MM | 520.0 MM | 535.0 MM | 550.0 MM | 565.0 MM | 580.0 MM | 595.0 MM | ||
| D | STANDOVER HEIGHT | 715.9 MM | 729.4 MM | 753.6 MM | 773.5 MM | 798.8 MM | 812.9 MM | 837.3 MM | ||
| E | BB OFFSET | -66.0 MM | -66.0 MM | -66.0 MM | -66.0 MM | -66.0 MM | -66.0 MM | -66.0 MM | ||
| F | BB HEIGHT | 273.0 MM | 273.0 MM | 273.0 MM | 273.0 MM | 273.0 MM | 273.0 MM | 273.0 MM | ||
| G | WHEEL BASE | 972.0 MM | 978.0 MM | 980.0 MM | 987.0 MM | 994.2 MM | 1,002.9 MM | 1,012.0 MM | ||
| H | BB CENTER TO TOPTUBE CENTER | 410.0 MM | 430.0 MM | 460.0 MM | 480.0 MM | 500.0 MM | 520.0 MM | 550.0 MM | ||
| I | BB CENTER TO TOP OF SEATTUBE | 470.0 MM | 490.0 MM | 520.0 MM | 540.0 MM | 560.0 MM | 580.0 MM | 610.0 MM | ||
| J | SEAT ANGLE | 74.5 ° | 74.5 ° | 74.0 ° | 73.6 ° | 73.3 ° | 73.0 ° | 72.5 ° | ||
| K | CHAINSTAY | 410.0 MM | 410.0 MM | 410.0 MM | 410.0 MM | 410.0 MM | 410.0 MM | 410.0 MM | ||
| L | REACH | 370.6 MM | 378.8 MM | 384.0 MM | 388.9 MM | 394.5 MM | 400.0 MM | 403.4 MM | ||
| M | STACK | 502.6 MM | 509.0 MM | 526.7 MM | 547.5 MM | 568.3 MM | 588.5 MM | 607.7 MM | ||
| N | STEM LENGTH | 90.0 MM | 90.0 MM | 100.0 MM | 110.0 MM | 110.0 MM | 120.0 MM | 120.0 MM | ||
| A | HEAD TUBE ANGLE | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° | ||
| B | HEAD TUBE LENGTH | 4.3 IN | 4.5 IN | 5.1 IN | 5.9 IN | 6.7 IN | 7.5 IN | 8.3 IN | ||
| C | TOP TUBE HORIZONTAL | 20.1 IN | 20.5 IN | 21.1 IN | 21.7 IN | 22.2 IN | 22.8 IN | 23.4 IN | ||
| D | STANDOVER HEIGHT | 28.2 IN | 28.7 IN | 29.7 IN | 30.5 IN | 31.4 IN | 32.0 IN | 33.0 IN | ||
| E | BB OFFSET | -2.6 IN | -2.6 IN | -2.6 IN | -2.6 IN | -2.6 IN | -2.6 IN | -2.6 IN | ||
| F | BB HEIGHT | 10.7 IN | 10.7 IN | 10.7 IN | 10.7 IN | 10.7 IN | 10.7 IN | 10.7 IN | ||
| G | WHEEL BASE | 38.3 IN | 38.5 IN | 38.6 IN | 38.9 IN | 39.1 IN | 39.5 IN | 39.8 IN | ||
| H | BB CENTER TO TOPTUBE CENTER | 16.1 IN | 16.9 IN | 18.1 IN | 18.9 IN | 19.7 IN | 20.5 IN | 21.7 IN | ||
| I | BB CENTER TO TOP OF SEATTUBE | 18.5 IN | 19.3 IN | 20.5 IN | 21.3 IN | 22.0 IN | 22.8 IN | 24.0 IN | ||
| J | SEAT ANGLE | 74.5 ° | 74.5 ° | 74.0 ° | 73.6 ° | 73.3 ° | 73.0 ° | 72.5 ° | ||
| K | CHAINSTAY | 16.1 IN | 16.1 IN | 16.1 IN | 16.1 IN | 16.1 IN | 16.1 IN | 16.1 IN | ||
| L | REACH | 14.6 IN | 14.9 IN | 15.1 IN | 15.3 IN | 15.5 IN | 15.7 IN | 15.9 IN | ||
| M | STACK | 19.8 IN | 20.0 IN | 20.7 IN | 21.6 IN | 22.4 IN | 23.2 IN | 23.9 IN | ||
| N | STEM LENGTH | 3.5 IN | 3.5 IN | 3.9 IN | 4.3 IN | 4.3 IN | 4.7 IN | 4.7 IN |
